FANUC Series 16i/18i/21i Additional Manual Page 6

Additional Manual
12841 Operation history signal selection address (No. 01)
12842 Operation history signal selection address (No. 02)
12843 Operation history signal selection address (No. 03)
.
.
.
.
12860 Operation history signal selection address (No. 20)
[Data type] Word
[Valid data range] 0 to 511
Specify the signal address for operation history signal selection. When the address is
set, the parameter of the corresponding bits becomes to 0.
If the value, which can not be set, is set to this parameter or the parameter of the
corresponding signal type is 0, the warning message “out of range” is displayed.
#7 #6 #5 #4 #3 #2 #1 #0
12881 (No. 01)
#7 #6 #5 #4 #3 #2 #1 #0
12882 (No. 02)
#7 #6 #5 #4 #3 #2 #1 #0
12883 (No. 03)
#7 #6 #5 #4 #3 #2 #1 #0
12900 (No. 20)
.
.
.
.
[Data type] Bit
Specify the bits for operation history signal selection. To select a signal as a history
target, set the related bit to 1. Otherwise, set it to 0.
If the parameter of the corresponding signal type is 0, the warning message “out of
range” is displayed.
Edit
Apprv.
Desig.
Sheet
TITLE
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i/18i/21i–A/B
Expansion of the setting range of signals on
o
p
eration histor
y
S
p
ecifications
A-90015E
2002.7.31
6
/
7
