  2. Series 30i-MODEL A, Tool axis direction tool length compensation

Series 30i-MODEL A, Tool axis direction tool length compensation Additional Manual Page 19

Additional Manual
A-79381E
Title
Draw
No.
17/23
page
FANUC Series 30i-MODEL A
Tool Axis Direction Tool Length
Compensation
Ed. Date Design Description
Date
Jan.16.’04 Design. Apprv.
19655 Axis number of the linear axis to which a rotation axis belongs
[Input type] Parameter input
[Data type] Integeraxis
[Valid data range] 0 - Max axes
This parapeter is used for tool axis direction tool length compensation.
When a rotation axis turns about a linear axis , the linear axis is referred to as an
axis to which the rotation axis belongs, and is set using this parameter. For a
rotation axis that belongs to no linear axis, or for a linear axis, 0 is set.
Example:
Axis configuration: X, Y, Z, C, A
Linear axis: X, Y, Z
Rotation axis: A (turning about the X-axis), C (turning about the Z-axis)
In the above case, set the following:
Axis number Axis name Setting
1X0
2Z0
3Y0
4C2
5A1
19656 Tool axis direction
[Input type] Parameter input
[Data type] Integerpath
[Valid data range] 1 - 3
Enter the tool axis direction when the two rotation axes are set at 0 degree.
Data Tool axis direction
1X-axis
2Y-axis
3Z-axis
Previous page
Next page

Contents Summary of Series 30i-MODEL A, Tool axis direction tool length compensation Additional Manual
