#7 #6 #5 #4 #3 #2 #1 #0
GST AER GTF
11329
GST AER GTF
[Input type] Parameter input
[Data type] Bit path
#4 GTF In dynamic graphic display, position considering the tool offset function (tool
length compensation, cutter/tool-nose radius compensation) is:
0: Drawn.
1: Not drawn.
#5 AER When tool path drawing using the dynamic graphic display function is started,
automatic erasure operation is:
0: Not performed.
1: Performed.
#7 GST If a command that cannot be displayed in dynamic graphic display is specified:
0: Drawing is continued without being stopped, ignoring the command.
1: Drawing is stopped.
11330 Scale for dynamic graphic display
[Input type] Parameter input
[Data type] Real path
[Valid data range] 0.01 to 100.0
Set a graphic range scale for drawing using the dynamic graphic display function.
11331 Graphic range center for dynamic graphic display
[Input type] Parameter input
[Data type] Real axis
[Unit of data] mm, inch, degree (machine unit)
[Minimum unit of data] Depend on the increment system of the applied axis
[Valid data range] 9 digit of minimum unit of data (refer to standard parameter setting table (A))
(When the increment system is IS-B, -999999.999 to +999999.999)
Set a graphic range center coordinate for drawing using the dynamic graphic display function.
Previous page
Next page
