⑤ When G31 (skip function), or G31.1, G31.2, or G31.3 (multistage skip function) is
specified, drawing is performed up to the specified position, regardless of the skip
signal.
⑥ When G60 (single direction positioning) is specified, drawing is performed directly
up to the specified position at all times even if the positioning direction is opposite.
3. Functions that perform different operations
If the following functions are specified, the operations described below result:
① G02.2/G03.2 (involute interpolation)
Circular interpolation is performed.
② G02.3/G03.3 (exponential interpolation)
Linear interpolation is performed only with linear axes.
③ G07 (virtual axis interpolation)
Circular interpolation is performed.
④ G07.1 (cylindrical interpolation)
Linear interpolation is performed only with linear axes.
⑤ G12.1 (polar coordinate interpolation)
Linear interpolation is performed only with linear axes.
5. Functions that are conditional in drawing execution
If the function below is specified, drawing may be executed, depending on the condition.
If the condition is not satisfied, the specification of the function is ignored.
① M198 (external subprogram call)
→ When a mode other than the MEM and RMT modes is selected
- Functions that do not support drawing
The following functions are ignored in drawing execution:
① G04 (dwell)
② G20, G21 (inch/metric switch)
③ Auxiliary function (M, S, T, B)
④ G22, G23 (stored stroke limit check on/off)
⑤ G10.6 (tool retract data setting)
⑥ G10.9 (programmable diameter/radius switch)
⑦ G81.1 (chopping)
⑧ G25/G26 (spindle variation detection on/off)
⑨ G10 (programmable data input)
NOTE
If G10 (programmable data input) is specified, drawing can be temporarily
stopped with the warning "UNAVAILABLE COMMAND IS IN DRAWING" by
setting the GST parameter (No.11329#7).
The following functions are warning in drawing execution:
① G02.4/G03.4 (three-dimensional circular interpolation)
② M198 (external subprogram call)
