FANUC Series 16i/18i MA Digitizing function Additional Manual Page 4
Additional Manual
2000/07/21 H. Shiobara
A-78209EN
FS16i/18i-MA
Digitizing function
Title
Drawing No.
Page
Descri
p
tionDateEdit
4/7
2. Parameters
Following parameters for each axes corresponding to each directions of probe moving
are set for reading the feedback of digitizing probe. Normally, the parameters for
X/Y/Z axes are set for reading the feedback of probe moving in X/Y/Z direction.
Data type: Bit axis
PM1 The 1st separate detector interface unit is:
0: not used.
1: used.
PM2 The 2nd separate detector interface unit is:
0: not used.
1: used.
Connector number of the 1st se
p
arate detector interface unit
Connector number of the 2nd se
p
arate detector interface unit
Data type : Byte axis
Data validity : 0 to 7
When the separate detector interface unit is used, each of these parameters sets
the value obtained by subtracting 1 from a separate detector interface unit
connector number for each axis. That is, values of 0 through 7 are set for
connector numbers 1 through 8. In addition, bits 6 and 7 of parameter No.1905
must be set. For an axis that does not use a separate detector interface unit, 0
must be set.
The user can freely specify the connector to be used for a given axis. When using
NOTE
After these parameters have been set, the power must be turned off
then back on for the settings to become effective.
NOTE
After these parameters have been set, the power must be turned off
then back on for the settings to become effective.
