Concerning addition of the Changing Active Offset Value with Manual Move Supplement to Manual Page 12

Supplement to Manual
#7 #6 #5 #4 #3 #2 #1 #0
5041 AOF
[ Input type ] Parameter input
[ Data type ] Bit
AOF When the manual feed-based active offset change mode is selected in a
reset state or a cleared state, the tool compensation:
0: Can be changed
1: Cannot be changed
However, even if “1” is set in parameter CLR(No.3402#6), it becomes the following
according to parameter CFH(No.3409#7).
[ When the CLR(No.3402#6) parameter is 1]
AOF(No.5041#0)=0 AOF(No.5041#0)=1
CFH(No.3409#7=0) Cannot be changed
CFH(No.3409#7=1) Can be changed
Cannot be changed
[Relation parameter]
#7 #6 #5 #4 #3 #2 #1 #0
3402 CLR
[ Input type ] Parameter input
[ Data type ] Bit
CLR The reset button on the MDI panel, external reset signal, reset and
rewind signal, and emergency stop signal
0: Cause reset state.
1: Cause clear state.
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
9
/
10
Date
Design
Descri
tion
Date
FANUC Series16i/18i/21i–MA/MB
Changing Active Offset Value
with Manual Move.
02 030205 Overall revision
001106 S. Isohata E. Genma
A-78535E
Previous page
Next page
