Concerning addition of the Changing Active Offset Value with Manual Move Supplement to Manual Page 6
Supplement to Manual
Example
The compensation value set at Z-axis of the offset number 10 becomes
54.700 + (-2.583) = 52.117 mm under the following conditions:
• Specified H code: H10
• Value set at Z-axis of the offset number 10: 54.700 mm
• Amount of movement caused by manual feed along the Z-axis:
-2.583 mm
2.4 Changing the cutter radius compensation
This function can change the cutter radius compensation identified by the offset number
corresponding to a D code specified during automatic operation. If there is no valid tool
compensation (for example, when no D code has been issued since cycle start), no cutter
compensation change takes place even when axis movement is made manually.
Linear axis movement can change the cutter radius compensation. Rotation axis
movement cannot change it. When the cutter radius compensation is being changed,
manual feed cannot cause movement along more than one axis at a time.
Example
The compensation at offset number 15 becomes
6.500 + 2.379 + (-0.572) = 8.307 mm under the following conditions:
• Specified D code: D15
• Value set at offset number 15: 6.500 mm
• Amount of movement caused by manual feed along the X-axis: 2.379 mm
• Amount of movement caused by manual feed along the Y-axis:-0.572 mm
2.5 Changing the workpiece origin offset
This function can change the workpiece origin offset of an individual axis of the
workpiece coordinate system corresponding to G54 to G59 or G54.1P1 to P48
specified during automatic operation. There is a currently valid workpiece
coordinate system. So, axis movement made by manual feed causes the
workpiece origin offset of that workpiece to be changed. In addition, movement
along any axis (regardless of axis types, such as linear axes or rotation axes) can
change the workpiece origin offset. Moreover, manual feed can be made along
more than one axis at a time, when the workpiece origin offset is being changed.
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
3
/
10
Date
Design
Descri
p
tion
Date
FANUC Series16i/18i/21i–MA/MB
Changing Active Offset Value
with Manual Move.
02 030205 Overall revision
001106 S. Isohata E. Genma
A-78535E
