Common settings of RISC board Additional Manual Page 10

Additional Manual

Page of 16

/ 16

Title

No.

FANUC Series 16i /18i –MA/MB

Common setting of RISC board

A-78442E

Page

　Newly registered　　　　　　　

Ver Date Design Description

01 01.03.16

Hosokawa

1.3 Restrictions

Restriction -1

The following commands can not be used in the AI High Precision Contour Control mode

or AI NANO High Precision Contour Control mode. The alarm is issued if the function

was used.

・ Custom macro

・ Exponential interpolation -G02.3,G03.3

・ Dwell -G04

・ High Speed Cutting Function relation -G05

(G05P10000 and G05P0 are excluded)

・ AI contour control -G05.1Q1,G5.1Q0

・ Hypothetical axis interpolation -G07

・ Advanced preview control -G08

(Please use AI High Precision Contour Control)

・ Polar coordinate interpolation -G12.1,G13.1

・ Polar coordinate command -G15,G16

・ Reference position return check -G27

・ Reference point return -G28

・ 2nd. Reference point return -G30

・ 3rd/4th reference point return -G30

・ Skip -G31

・ Thread cutting -G33

・ Automatic tool length measurement -G37

・ Normal direction control -G40.1,G41.1,G42.1

・ Cutter compensation B -G41,G42,G39

(Cutter compensation C is available)

・ 3-dimensional tool compensation -G41

・ Wheel wear compensation -G41

・ Tool offset -G45,G46,G47,G48

・ Local coordinate system -G52

・ Machine coordinate system -G53

・ Single direction positioning -G60

・ Automatic corner override -G62

・ Tapping mode -G63

・ Macro call -G65,G66,G67

(SubProgram call is available)

・ Figure copying -G72.1,G72.2

・ Simple electric gear box -G80,G81

・ Functions for hobbing machine -G80,G81

・ External operation function -G81

・ Chopping function -G81.1

・ Setting a workpiece coordinate system -G92

・ Workpiece coordinate system preset -G92.1

Contents Summary of Common settings of RISC board Additional Manual

Page 1TECHNICAL REPORT (MANUAL) No.TMN 01/052E Date : Mar. 29, 2001 General Manager of Software Laboratory FANUC Series 16i/18i-MA/MB Common setting of RISC board 1. Communicate this report to: Your information only ○ GE Fanuc-N, GE Fanuc-E FANUC Robotics MILACRON ○ Machine tool builder Sales agency End u
Page 2FANUC Series 16i /18i –MA/MB Common setting of RISC board This specification may be modified for improvement without notice. FANUC Series 16i /18i –MA/MB Title Common setting of RISC board 01 01.03.16 Hosokawa Newly registered No. A-78442E Ver Date Design Description Page 1/15
Page 3Contents 1. 3-Dimensional Circular Interpolation ......................................................................................................................3 General............................................................................................................................
Page 41 Common setting of RISC board General The following functions are executed at high speed with RISC processor. • AI high precision contour control (FANUC Series 16i/18i-MA/MB) • AI NANO high precision contour control (FANUC Series 16i-MA/MB) • Tool center point control (FANUC Series 16i-MA/MB) • Too
Page 51.1 Signal HPCC mode signal MHPCC (F066#6) [Classification] Output signal [Function] Indicates that the system is set to the following functions mode • AI high precision contour control • AI NANO high precision contour control • Tool center point control • Tool axis compensation in tool axis directi
Page 6• G41 or G42 is specified in a program when the parameter RCR(No19600#5)=1 (Cutter compensation C) The signal is set to 0 if the all following function is canceled by the program or by the reset. • G05 P0 is specified in a program. (AI high precision contour control or AI NANO high precision contour
Page 71.2 Parameter 7510 Maximum number of axes in High Precision Contour Control [In pu t t ype] P a r a m et er In pu t [Data type] Byte [Va lid da t a r a n ge] 1, 2, 3,=t o t h e m a xim u m n u m ber of con t r ol a xes This parameter specifies the maximum number of axes to controlled by High Precisi
Page 8#7 #6 #5 #4 #3 #2 #1 #0 19600 RCR R3D RRO RFX RMI RSC [In pu t t ype] P a r a m et er In pu t [Da t a t ype] Bit #0 RS C Sca lin g fu n ct ion is execu t ed 0: at the CNC 1: at the RISC as 5-axis control mode #1 RMI P r ogr a m m a ble m ir r or im a ge is execu t ed 0: at the CNC 1: at the RISC as
Page 9#7 #6 #5 #4 #3 #2 #1 #0 8485 G81 [In pu t t ype] P a r a m et er In pu t [Da t a t ype] bit #1 G81 In AI high precision contour control mode or in AI NANO high precision contour control mode, the hole machining canned cycle is: 0: Disabled（Alarm (P/S5000) occurs）） 1: Enabled FANUC Series 16i /18i –M
Page 101.3 Restrictions Restriction -1 The following commands can not be used in the AI High Precision Contour Control mode or AI NANO High Precision Contour Control mode. The alarm is issued if the function was used. ・ Custom macro ・ Exponential interpolation -G02.3,G03.3 ・ Dwell -G04 ・ High Speed Cutting
Page 11・ Feed per revolution -G95 ・ Constant surface speed control -G96,G97 ・ Infeed control -G160,G161 Restriction -2 The following functions can not be used in the AI High Precision Contour Control mode, the AI NANO High Precision Contour Control mode or the 5-axis control mode. ・ Flexible synchronous co
Page 12Restriction –5 When the following function is used, the function which executed with RISC processor cannot be used. ・ Angular axis control ・ Arbitary angular axis control Restriction -6 The following modal G code are placed in the cleared state when the reset is executed in AI high precision contour
Page 131.4 The Function list which can be used Item Specifications Note Axis control Controlled axes 3 axes Controlled paths 1-path Simultaneously controlled axes 2 axes Controlled axis expansion Up to 8 axes Simultaneously controlled axis Up to 6 axes expansion Axis control by PMC The axis which is used i
Page 14Item Specifications Note Operation Automatic operation MDI operation The AI high precision contour control mode or the AI NANO high precision contour control mode is automatically canceled once and the buffering is inhibited if the MDI operation is used in the AI high Precision Contour Control mode
Page 15Item Specifications Note Feed functions F1 digit feed Using the manual pulse generator can not change Feedrate. Inverse time feed G93 External deceleration Look ahead liner-type acceleration/ deceleration before interpolation. Look ahead Bell-type acceleration/ Acceleration change time constant dece
Page 16Item Specifications Note Miscellaneous/spindle functions Miscellaneous function The AI high precision contour control mode or the AI NANO high precision contour control mode is automatically canceled once and the buffering is inhibited if this function is used in the AI high Precision Contour Contro
