Common settings of RISC board Additional Manual Page 15

Additional Manual
Title
No.
FANUC Series 16i /18i –MA/MB
Common setting of RISC board
A-78442E
Page
14/
15
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
Item Specifications Note
Feed functions
F1 digit feed Using the manual pulse generator can not change Feedrate.
Inverse time feed G93
External deceleration
Look ahead liner-type acceleration/
deceleration before interpolation.
Look ahead Bell-type acceleration/
deceleration before interpolation
Acceleration change time constant
type
Program input
Tape code Automatic recognition of EIA/ISO
Program format Word address format
Control in/out
Optional block skip
Absolute/incremental programming G90/G91
Input unit 10 time multiply
Plane selection G17,G18,G19
Rotary axis roll over
Workpiece coordinate system selection G54～G59 The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if this function is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode.
Addition of workpiece coordinate sys-
tem pair
48 sets / 300 sets The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if this function is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode.
Manual absolute ON/OFF
Programmable parameter input G10 The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if this function is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode.
External memory and sub program
calling function
M198
Subprogram call M98
Circular interpolation by R programming
Scaling G50,G51 The mode of AI high precision contour control or of AI NANO
high precision contour control is permitted to change ON and OFF
in scaling mode by setting the parameter.
The alarm (P/S5012) occurs if the mode of AI high precision
contour control or of AI NANO high precision contour control is
changed in scaling mode (G51) when the parameter is not set.
The scaling mirror image by a negative magnification can not be
done.
Coordinate system rotation G68,G69 The mode of AI high precision contour control or of AI NANO
high precision contour control is permitted to change ON and OFF
in coordinate system rotation mode by setting the parameter.
The alarm (P/S5012) occurs if the mode of AI high precision
contour control or of AI NANO high precision contour control is
changed in coordinate system rotation mode (G51) when the
parameter is not set.
3-dimensional coordinate system
conversion
G68,G69 The mode of AI high precision contour control or of AI NANO
high precision contour control is permitted to change ON and OFF
in 3-dimensional coordinate system conversion mode by setting
the parameter. The alarm (P/S5012) occurs if the mode of AI high
precision contour control or of AI NANO high precision contour
control is changed in 3-dimensional coordinate system conversion
when the parameter is not set.
