Common settings of RISC board Additional Manual Page 14

Additional Manual
Title
No.
FANUC Series 16i /18i –MA/MB
Common setting of RISC board
A-78442E
Page
13/
15
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
Item Specifications Note
Operation
Automatic operation
MDI operation The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if the MDI operation is used in the AI
high Precision Contour Control mode or in the AI high Precision
Contour Control mode. At this time, G05P10000 or G05P0 can
not be used by the MDI operation.
Cycle start/Feed hold
Program stop/Program end
Reset
Program restart
Dry run
Single block
Interpolation functions
Positioning G00 The AI high precision contour control function or AI NANO high
precision contour control functions except the advanced preview
feed-forward function , multi buffer function , and the NANO
interpolation become invalid.
Exact stop mode G61
Exact stop G09
Cutting mode G64
Linear interpolation G01
Circular interpolation G02,G03
Helical interpolation (Circular interpolation) + (Linear
interpolation for up to 2 axes)
Helical interpolation B (Circular interpolation) + (Linear
interpolation for up to 4 axes)
Involute interpolation G02.2,G03.2
3-dimensional circular interpolation G02.4,G03.4 The position is checked at the end point of the block which cancel
3 dimensional circular interpolation or at the end point of the
previous block of the 3 dimensional circular interpolation if 3
dimensional circular interpolation is used except in AI high
precision contour control mode or AI NANO high precision
contour control mode.
Smooth interpolation G05.1 This function can be used in AI high precision contour control
mode or AI NANO high precision contour control mode.
NURBS interpolation G06.2 This function can be used in AI high precision contour control
mode or AI NANO high precision contour control mode.
Cylindrical interpolation G07.1
Cylindrical interpolation
cutting point control
G07.1
This function can be used in AI high precision contour control
mode or AI NANO high precision contour control mode.
Conical / spiral interpolation G02,G03
Feed functions
Feed per minute G94
Cutting feedrate clamp
Linear acceleration/deceleration of
cutting feed after interpolation
Bell-type acceleration/deceleration of
cutting feed after interpolation
Feedrate override 0 to 254% (1% step)
2nd. Feedrate override 0 to 254% (1% step)
