Common settings of RISC board Additional Manual Page 7
Additional Manual
Title
No.
FANUC Series 16i /18i –MA/MB
Common setting of RISC board
A-78442E
Page
6/
15
Newly registered
Ver Date Design Description
01 01.03.16
Hosokawa
1.2 Parameter
7510 Maximum number of axes in High Precision Contour Control
[Input type] Parameter Input
[Data type] Byte
[Valid data range] 1, 2, 3,
=
to the maximum number of control axes
This parameter specifies the maximum number of axes to controlled by High
Precision Contour Control.
Example) Axis configuration is X, Y, Z, A, B, and C from the 1st axis in this order
and to make HPCC valid to the 4th axis (A), set this parameter to 4. In this case,
HPCC is also effective for the X, Y, Z axes.
X, Y, Z, A axes Axes on which HPCC is valid
B, C axes Axes on which HPCC is not valid.
#7 #6 #5 #4 #3 #2 #1 #0
8480
RI2 RI1 RI0
[Input type] Parameter Input
[Da ta type] Bit
Be sure set this parameter to the following settings( Type-A or Type-B)
RI2 RI1 RI0
備考
Type-A 0 0 1 setting for the compatibility
with conventional model
Type-B 0 0 0 Recommended setting
This parameter is recommended to be set in type-B in the system of model B.
Contents Summary of Common settings of RISC board Additional Manual
