FANUC Series 16i/18i/160i/180i/160is/180is-TA
Increment System 1/100
A-78347E
mm input / mm output
Increment system
IS-B IS-C IS-D
Least input increment [mm] 0.001 0.0001 0.00001
Least command increment (Diameter) [mm] 0.0005 0.00005 0.000005
Least command increment (Radius) [mm] 0.001 0.0001 0.00001
Max. programmable dimension [mm] +-99,999.999 +-9,999.9999 +-999.99999
Max. rapid traverse [mm/min] 240,000 100,000 10,000
Feedrate range (Feed per minute) [mm/min] 1 to 240,000 1 to 100,000 1 to 10,000
Feedrate range (Feed per revolution) [mm/rev] 1 to 500
Incremental feed [mm/step] 0.001, 0.01, 0.1, 1 0.0001, 0.001, 0.01, 0.1 0.00001, 0.0001, 0.001, 0.01
Tool compensation value (Standard) [mm] 0 to +-999.999 0 to +-999.9999 0 to +-99.99999
Tool compensation value (seven digits) [mm] 0 to +-9,999.999 0 to +-9,999.9999 0 to +-999.99999
Backlash compensation [Detection unit] 0 to 255
Dwell time [sec] 0 to 99,999.999 0 to 9,999.9999 0 to 999.99999
Max. jog feed(100%) [mm/min] 32,767 12,287 1,229
