FANUC Series 16i/18i/160i/180i/160is/180is-TA
Increment System 1/100
A-78347E
inch input / mm output
Increment system
IS-B IS-C IS-D
Least input increment [inch] 0.0001 0.00001 0.000001
Least command increment (Diameter) [mm] 0.0005 0.00005 0.000005
Least command increment (Radius) [mm] 0.001 0.0001 0.00001
Max. programmable dimension [inch] +-3,937.0078 +-393.70078 +-39.370078
Max. rapid traverse [mm/min] 240,000 100,000 10,000
Feedrate range (Feed per minute) [inch/min] 0.01 to 9,600.00 0.01 to 4,000.00 0.01 to 400.00
Feedrate range (Feed per revolution) [inch/rev] 0.000001 to 9.999999
Incremental feed [inch/step] 0.0001, 0.001, 0.01, 0.1 0.00001, 0.0001, 0.001, 0.01 0.000001, 0.00001, 0.0001, 0.001
Tool compensation value (Standard) [inch] 0 to +-99.9999 0 to +-99.99999 0 to +-9.999999
Tool compensation value (seven digits) [inch] 0 to +-999.9999 0 to +-999.99999 0 to +-99.999999
Backlash compensation [Detection unit] 0 to 255
Dwell time [sec] 0 to 9,999.9999 0 to 999.99999 0 to 99.999999
Max. jog feed(100%) [inch/min] 1,290.00 1,228,73 122.87
