Increment System 1/100 Additional Manual Page 7

Additional Manual
DS0100-04
01 00.09.18 Newl
y
Re
g
istered
6/
PAGE
EDT.
DATE
DESIGN
DESCRIPTION
TITLE
No.
FANUC Series 16i/18i/160i/180i/160is/180is-TA
Increment System 1/100
A-78347E
inch input / inch output
Increment system
IS-B IS-C IS-D
Least input increment [inch] 0.0001 0.00001 0.000001
Least command increment (Diameter) [inch] 0.00005 0.000005 0.0000005
Least command increment (Radius) [inch] 0.0001 0.00001 0.000001
Max. programmable dimension [inch] +-9,999.9999 +-999.99999 +-99.999999
Max. rapid traverse [inch/min] 9,600 4,000 400
Feedrate range (Feed per minute) [inch/min] 0.01 to 9,600. 0.01 to 4,000. 0.01 to 400.
Feedrate range (Feed per revolution) [inch/rev] 0.000001 to 9.999999
Incremental feed [inch/step] 0.0001, 0.001, 0.01, 0.1 0.00001, 0.0001, 0.001, 0.01 0.000001, 0.00001, 0.0001, 0.001
Tool compensation value (Standard) [inch] 0 to +-99.9999 0 to +-99.99999 0 to +-9.999999
Tool compensation value (seven digits) [inch] 0 to +-999.9999 0 to +-999.99999 0 to +-99.999999
Backlash compensation [Detection unit] 0 to 255
Dwell time [sec] 0 to 9,999.9999 0 to 999.99999 0 to 99.999999
Max. jog feed(100%) [inch/min] 1,290.00 1,228.73 122.87
