FS 16i/18i/21i/0i-Model B, Fanuc Standard Color Scheme Setting Function Additional Manual Page 4
Additional Manual
2 Details
2.1 FANUC standard color scheme 1 (new FANUC standard color scheme) setting
When all standard color data parameters (No.6561 to No.6595) of COLOR1 are
set to 0, if the parameter NDC (No.13101#6) is set to 1 and CNC is turned off and
on again, the color scheme (color palette value) is changed to FANUC standard
color scheme 1. This is new FANUC standard color scheme.
The content of FANUC standard color scheme 1 (new FANUC standard color
scheme) shows in the following table.
• FANUC Series 16i/18i/21i-MODEL B
Color No. RED GREEN BLUE
1 8 0 0
2 0 0 0
3 5 5 5
4 15 15 0
5 15 0 15
6 1 6 6
7 0 0 0
8 6 6 15
9 0 11 11
10 8 8 15
11 12 11 11
12 15 15 15
13 12 11 11
14 4 4 4
15 11 11 11
• FANUC Series 0i-MODEL B
Color No. RED GREEN BLUE
1 8 0 0
2 0 0 0
3 5 5 5
4 15 15 0
5 15 0 15
6 1 6 6
7 0 0 0
8 4 11 9
9 0 11 11
10 4 11 9
11 12 11 11
12 15 15 15
13 12 11 11
14 4 4 4
15 11 11 11
NOTE) : In this gray part, FANUC standard color scheme 1 is a part
different compared with FANUC standard color scheme 2.
A-79019E
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Jan.27.’03 Desig. Apprv.
FANUC Series 16i/18i/21i/0i – MODEL B
Specifications of
FANUC standard color scheme setting function
3/6
