2.2 FANUC standard color scheme 2 (former FANUC standard color scheme) setting
When all standard color data parameters (No.6561 to No.6595) of COLOR1 are
set to 0, if the parameter ODC (No.13101#7) is set to 1 and CNC is turned off and
on again, the color scheme (color palette value) is changed to FANUC standard
color scheme 2. This is former FANUC standard color scheme.
The content of FANUC standard color scheme 2 (former FANUC standard color
scheme) shows in the following table.
Color No. RED GREEN BLUE
1 8 0 0
2 0 8 0
3 8 8 0
4 15 15 0
5 15 0 15
6 0 8 8
7 3 1 1
8 0 0 15
9 0 11 11
10 15 15 15
11 10 9 9
12 15 15 15
13 12 11 11
14 4 4 4
15 12 11 11
A-79019E
Sheet
Title
Draw
No.
Ed. Date Design Description
Date Jan.27.’03 Desig. Apprv.
FANUC Series 16i/18i/21i/0i – MODEL B
Specifications of
FANUC standard color scheme setting function
4/6
