Connecting manual for detachable LCD/MDI Type B Additional Manual Page 10
Additional Manual
EDIT
FANUC LTD
SHEE
DRAW. NO. CUST
.
TITLE
9/14
DESCRIPTIONDESIG.DATE
01
00.10.2 Akash
Newl
y
Detachable LCD/MDI Type B
A-80049E
5.1 Detail of video signal cable J185
Recommended wire : A66L-0001-0371 (five coaxial cable batch shield) <HITACHI telegraph>
Recommended connector JA1 side connector : FI40B-20S (type of soldering 15 pins,
case ; FI-20-CV5 <HIROSE electrical equipment>
Recommended connector CA72 side connector : DBM-25S
lock metal fittings : D20418-J9 <HONDA communication>
The largest length of the cable : The cable J185 added to J182 is 50m
VDR
0V
VDG
0V
VDB
0V
HSYNC
0V
VSYNC
0V
FG
2
15
3
16
4
17
6
19
5
18
1
CNC JA1
(PCR-EV20MDT)
1VDR11
20V12 VSYNC
3VDG13
40V14 0V
5VDG15
60V16 0V
7 17
8 18 HSYNC
9 19
10 20
J185
VDR
0V
VDG
0V
VDB
0V
HSYNC
0V
VSYNC
0V
1
2
3
4
5
6
18
16
12
14
JA1
shield
75
Ω
the coaxial
cable
CA72
Terminal unit CA72
(DBM-25S)
1FG14
2VDR15 0V
3VDG16 0V
4VDB17 0V
5VSYNC18 0V
6HSYNC19 0V
7 20 0V
8(TXD)21 0V
9(*TXD)22 (RXD)
10 23 (*RXD)
11 24
12 25
13
Note
1.
The FG pin of connector CA72 is connected to the cabinet.
