FANUC Servo Amplifier ßi Series I/O Link Option Modification from I/O Link ß Additional Manual Page 22

Additional Manual
FANUC SERVO AMPLIFIER βi series I/O Link Option
Modification from I/O Link β
EDIT
DRAW. NO. CUST
TITLE
DESCRIPTION
DESIG.
DATE
A-79487E
22
/
23
01
04.03.15
SHEET
Newly designed
Motor model
α4
5000is
αC4
3000i
β12
3000is
α4
4000i
β22
2000is
αC8
2000i
α8
3000i
β0.4
5000is
Motor
specification
0215 0221 0078 0223 0085 0226 0227 0114
Symbol Motor ID No. 265 271 272 273 274 276 277 280
BITPRM 19 00001000 00001000 00001100 00000000 00001100 00001000 00000000 00000000
PK1 70 420 1240 402 993 1184 1276 787 100
PK2 71 -1748 -6415 -2217 -4260 -6800 -6288 -4184 -430
PK3 72 -1276 -1309 -1304 -1311 -1331 -1326 -1325 -2463
PK1V 73 63 113 166 104 236 146 110 7
PK2V 74 -560 -1009 -1494 -931 -2121 -1310 -985 -59
PK4V 75 -8235 -8235 -8235 -8235 -8235 -8235 -8235 -8235
PPMAX 76 21 21 21 21 21 21 21 21
PDDP 77 1894 1894 1894 1894 1894 1894 1894 1894
PVPA 78 -8974 -5915 -5140 -11789 -3612 -3854 -6420 0
PALPH 79 -3641 -1500 -3500 -180 -3000 -1236 -2000 0
TQLIM 80 7282 7282 7282 8010 7282 7282 8010 4660
POVC1 81 32373 32590 32491 32610 32428 32434 32579 32640
POVC2 82 4942 2225 3465 1979 4249 4170 2363 1603
POVCLMT 83 14731 6612 10311 5879 12656 12420 7020 4759
AALPH 84 12288 12288 16384 8192 16384 8192 8192 20480
DBLIM 85 0 0 0 15000 0 0 15000 0
MGSTCM 86 8 1289 1814 32 0 1552 776 30
DETQLM 87 10295 3900 7930 5130 2866 3880 3870 10290
NINTCT 88 646 2544 1194 1443 2459 2380 2103 400
MFWKCE 89 1667 5000 3000 2000 5000 4500 3500 0
MFWKBL 90 3847 1812 2056 3338 562 1550 1815 0
EMFCMP 99 0 0 0 -5130 -5130 0 0 -12850
PK2VAUX 101 0 0 0 0 0 0 0 0
TRQCST 112 127 190 418 201 692 277 369 22
MDLCST 115 1127 626 845 678 596 482 641 10651
PHDLY1 118 7690 3855 5138 6670 3350 3860 0 7690
PHDLY2 119 12840 8995 8990 8980 8979 8990 0 12820
Motor model
β0.5
5000is
β1
5000is
α8
4000is
α12
4000is
αC12
2000i
α12
3000i
αC22
2000i
α22
3000i
Motor
specification
0115 0116 0235 0238 0241 0243 0246 0247
Symbol Motor ID No. 281 282 285 288 291 293 296 297
BITPRM 19 00000000 00000000 00001000 00001000 00000000 00000000 00001000 00000000
PK1 70 88 318 550 570 1875 1701 2320 1750
PK2 71 -818 -1819 -3449 -3358 -9137 -6391 -10593 -6000
PK3 72 -2415 -2388 -1307 -1319 -1339 -1315 -1347 -1345
PK1V 73 6 6 32 51 273 188 264 194
PK2V 74 -57 -51 -287 -454 -2445 -1681 -2368 -1733
PK4V 75 -8235 -8235 -8235 -8235 -8235 -8235 -8235 -8235
PPMAX 76 21 21 21 21 21 21 21 21
PDDP 77 1894 1894 1894 1894 1894 1894 1894 1894
PVPA 78 0 -11525 -7685 -5898 -1804 -8199 -2597 -5136
PALPH 79 0 -500 -2000 -3000 -2500 -747 -1942 -2800
TQLIM 80 5826 6554 7282 7282 7282 7282 8010 7282
POVC1 81 32674 32695 32690 32653 32317 32552 32348 32542
POVC2 82 1178 915 978 1435 5644 2702 5248 2820
POVCLMT 83 3497 2714 2901 4259 16838 8031 15648 8384
AALPH 84 20480 20480 0 0 8192 8192 4096 12288
DBLIM 85 0 0 0 0 15000 15000 0 15000
MGSTCM 86 30 30 519 521 0 32 1548 1291
DETQLM 87 10290 10290 7268 6174 2168 0 2600 0
NINTCT 88 1009 1763 2106 1592 4150 2388 3695 3272
MFWKCE 89 0 0 4000 2000 12000 2000 4000 4500
MFWKBL 90 0 0 2580 2575 1044 2568 1046 1301
EMFCMP 99 -12850 -12850 0 0 0 0 0 0
PK2VAUX 101 0 0 0 0 0 0 0 0
TRQCST 112 42 89 562 696 350 517 680 929
MDLCST 115 11014 12232 2197 1389 258 376 267 364
PHDLY1 118 7690 11560 5150 6174 5150 0 2070 0
PHDLY2 119 12820 12880 8990 8990 8990 0 9000 0
