FANUC Series 16i/18i/21i-MB
Parameter check sum function Specifications
A
-79242EN
Drawing No.
Title
Page
In case that the machining condition selecting function is used,
parameters in the following table are also excluded from the check
sum.
Parameters excluded from the check sum
(machining condition selecting function) (1/2)
Parameter No. Meaning of data
1432 Maximum cutting feed rate for each axis in the AI
contour control mode or look ahead control mode
1730 Maximum feed rate for arc radius R
1731 Arc radius value corresponding to a maximum feed rate
1769 Time constant for linear acceleration/deceleration or
bell–shaped acceleration/deceleration during cutting
feed for each axis
1770 - 1771 Parameter (for look–ahead control) for setting an
acceleration for linear acceleration/deceleration before
interpolation
1772 Time constant for bell–shaped acceleration/deceleration
of acceleration time fixed type before look–ahead
interpolation
1783 Allowable speed difference for the speed difference
based corner deceleration function (linear
acceleration/deceleration before interpolation)
1785 Parameter for determining an allowable acceleration
when the feed rate is set by acceleration
1788 Permissible acceleration change level for each axis in
speed control based on acceleration changes for jerk
control.
1789 Permissible acceleration change level for each axis in
speed control based on acceleration changes for jerk
control in AI nano contouring control when linear
interpolation is repeated.
1790 Ratio of the jerk change time in smooth bell-shaped
acceleration/deceleration before interpolation.
8400 - 8401 Parameter for determining a linear
acceleration/deceleration before interpolation
8410 Allowable velocity difference in velocity determination
considering the velocity difference at corners
8416 Look–ahead bell–shaped acceleration/deceleration
before interpolation
8470 Parameter for determining allowable acceleration in
velocity calculation considering acceleration
13634 Level in selecting at the present moment of the AI
contour control mode or look ahead control mode
13680 Level in selecting at the present moment of at the time
of high-precision contour control mode use.
