3.SELECTING A MOTOR SPECIFICATIONS FOR THE αiS/αi SERIES B-65262EN/03

- 50 -

Inertia of a heavy object moving along a straight line (table, workpiece, etc.)

SI unit

][

mkg

J ⋅×=

W : Weight of the object moving along a straight line [kg]

l : Traveling distance along a straight line per revolution of the

motor [m]

Gravitational system of units

][

2980

scmkgf

J ⋅⋅×=

W : Weight of the object moving along a straight line [kgf]

l : Traveling distance along a straight line per revolution of the

motor [cm]

Example)

When W is 1200(kg) and l is 20(mm), J

of a table and

workpiece is calculated as follows:

=1200×(0.020÷2÷π)

=0.01216 [kg⋅m

] =0.1241[kgf⋅cm⋅s

]

Inertia of an object whose speed is increased above or decreased below the

speed of the motor shaft

The inertia applied to the motor shaft by inertia J

is calculated as

follows:

orJ

J ××=

: Inertia before the speed is changed

: Number of teeth when the gear connection

1/Z : Deceleration ratio
