FS 16i/18i/21i-MB/TB Machine Alarm Diagnosis Specifications Additional Manual Page 11

Additional Manual
A-78622E
Edit
Apprv.
Desig.
Sheet
Title
Draw
No.
11/12
Date
Design
Descri
p
tion
Date
FANUC Series 16i /18i /21i -MB/TB
Machine Alarm Diagnosis
Specifications
2001.10.19
M.Kobayashi HKochiya
02 2001.11.07
A
dd
p
arameter, etc
2.4.Jump from CNC guidance table to MTB's guidance table
As a result of CNC alarm diagnosis, the alarm may be caused by machine trouble.
Considering such a case, it is possible to jump to MTB's guidance table from CNC
guidance table by the special message IDs starting with "M".
If the flowing special message IDs stating with "M" are created in MTB's guidance table,
a jump to MTB's guidance table from CNC guidance table becomes available.
Reserved message IDs
No
.
Message ID Alarm name Presumed cause
1 M205 Rigid mode DI
OFF
The rigid mode DI signal (G061.0) is not
set to 1 when the rigid tapping is
executed.
2 M409 Abnormal load
detected
A mechanical collision or twist occurred,
resulting in a load torque higher than a
normal operation value.
3 M410 Excessive stop
error
A mechanical collision or twist occurred,
disabling an axis from reaching a target
position.
4 M411 Excessive move
error
A mechanical collision or twist occurred,
disabling an axis from moving.
5 M420 Excessive torque
difference
Two axes to be moved synchronously lost
mechanical synchronism with each other,
resulting in a large torque difference.
6 M421 Excessive
semi-closed loop
error
With a closed-loop machine, a shift
occurred between the motion of the motor
and the motion of the separate detector
for a cause such as a mechanical twist.
7 M436 OVC alarm A mechanical collision or twist occurred,
resulting in a large load and the flow of an
excessive current.
Caution
All message IDs starting with "M" are reserved for a jump to MTB's guidance
table from a CNC guidance table.
In the future, a message ID to which a jump is made from a CNC guidance
table may be added. So, do no use a message ID starting with "M" which
may or may not be included in the table above for the other purpose.
