NOTE
・ This function is enabled when the TDC(No.13201#0) is set to 1.
・ The max. setting pages is 20.
・ This function is necessary to terminal code(-1).
・ If any item required the option is specified without the option, the item is
displayed as blank space in the screen.
・ The item after the terminal code is not displayed.
(Example)
N1→ R1 (No.), N2→R2 (TYPE-NO.), N3→ R3 (MG), N4→ R-1 (Terminal
code), N5→R4 (POT).
Item "NO., TYPE-NO., MG” are only displayed.
・ Customization of the tool management data table screen is initialized by
executing G10 L77 P3 command.
・ In the case of specified invalid value for R, tool management data table
screen is displayed as blank space.
