FS 16i/18i/21i-MB/TB, Expansion Tool Management Function Additional Manual Page 16

Additional Manual
2003.6.30
1.4 Protection for various tool management data by the key
signal
This function is possible to protect tool management data by the key signal.
Signal
Tool management data
protection signal
TKEY0 to TKEY5
<G330#0 to #5>
[Classification] Input Signal
[Function] Enables the changing of tool management data from the MDI.
When the parameter No.13204#0 TDL = 0
・ Disables the tool management data protection signal.
When the parameter No.13204#0 TDL = 1
・ TKEY0: Enables the input of tool type number (T-code).
・ TKEY1: Enables the input of tool management information (T-INFO).
・ TKEY2: Enables the input of tool life counter (L-COUNT), maximum of
tool life(MAX-LIFE), previous notice life (NOTICE-L), tool life
state(L-STATE).
・ TKEY3: Enables the input of tool compensation (tool length
compensation number, cutter compensation number, etc.).
・ TKEY4: Enables the input of spindle speed(S), feedrate(F).
・ TKEY5: Enables the input of custamaizing data (CUSTOM0 to
CUSTOM20).
[Operation] When a signal is set to 0, the input for data is disabled.
When a signal is set to 1, the input for data is enabled.
Singnal address
#7 #6 #5 #4 #3 #2 #1 #0
G330 TKEY5 TKEY4 TKEY3 TKEY2 TKEY1 TKEY0
Edit
16/26
Data Signature
Description
FANUC Series 16i/18i/21i-MB/TB
Expansion Tool Management Function
A-79171
Drawing No.
Title
Page
Previous page
Next page
