FANUC Series 16i/18i-MB/18i-MB5 Small-Hole Peck Rigid Tapping, Specifications Additional Manual Page 12

Additional Manual
2002/08/19 T.Inagaki
Alarm and message
Number Message Descriptions
5215 PECK RGTAP CAN'T BE
COMMANDED
・ The small-hole peck rigid-tapping
was specified during HPCC mode
or the advanced preview control
mode.
・ The small-hole peck rigid-tapping
was specified during the
three-dimensional coordinate
conversation mode.
・ The M code, that specifies
small-hole peck rigid-tapping mode,
is specified and other M-code is
specified in the same block.
Diagnosis scresn
520 Total number of retract operations during cutting since G84 was issued.
521 Tool number of retract operations due to reception of the overload torque
signal since G84 was issued
The indications of Nos. 520 and 521 are cleared by G80.
522 Coordinates at which the tapping axis started retracting
(least input command)
523 Difference between the previous and current coordinates at which the
tapping axis started retracting (least input increment: previous-current)
The indicates of Nos. 522 and 523 are cleared by M-code, that specifies the
small-hole peck drilling cycle mode, or the small-hole peck rigid-tapping
mode.
A-78641EN
FANUC Series 16i/18i–MB/18i–MB5
Small-hole peck rigid tapping
Title
Drawing No.
Page
Descri
p
tionDate Edit
12/14
Previous page
Next page
