FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece Coordinate Command Additional Manual Page 16
Additional Manual
A-90078E
Mirror image
In case that parameter PCA (No.11104#0) is 1, mirror image is available
during Path Table Operation.
In case that parameter PCA (No.11104#0) is 0, mirror image is not available
during Path Table Operation.
Tool geometric compensation
In case that parameter PCA (No.11104#0) is 1, tool geometric compensation
which was revised before Path Table Operation is valid during Path Table
Operation, too.
Tool wear compensation
In case that parameter PCA (No.11104#0) is 1, tool wear compensation which
was revised before Path Table Operation is valid during Path Table Operation,
too.
Tool length compensation
In case that parameter PCA (No.11104#0) is 1, tool length compensation (G43,
G44) which was revised before Path Table Operation is valid during Path
Table Operation, too.
Tool nose radius compensation
Cutter compensation C
P/S alarm No.452(dist_alm_no=34) occurs if Path Table Operation starts
during tool nose radius compensation or cutter compensation C.
Programmable mirror image
P/S alarm No.452 (dist_alm_no=34) occurs if Path Table Operation starts
during programmable mirror image (G51.1).
Mirror image for double turret
P/S alarm No.452 (dist_alm_no=34) occurs if Path Table Operation starts
during Mirror image for double turret (T:G68).
Coordinate system rotation
Three-dimensional coordinate conversion
P/S alarm No.452(dist_alm_no=34) occurs if Path Table Operation starts
during Coordinate system rotation (M:G68, T:G68.1) or Three-dimensional
coordinate conversion (M:G68, T:G68.1).
Scaling(M:G51)
P/S alarm No.452(dist_alm_no=34) occurs if Path Table Operation starts
during Scaling(M:G51).
Sheet
Title
Draw
No.
FANUC Series 30i/31i
Specifications of Path Table Operation
Workpiece coordinate command
FANUC LTD
16/17
Ed. Date Design Description
Date Jun.06.’5 Desig. T.Watanabe Apprv. Y.Takeuchi
