FANUC Series 30i/31i-A Specifications of Path Table Operation Workpiece Coordinate Command Additional Manual Page 8
Additional Manual
A-90078E
FOCAS2 Window Function
Parameter PCA(No.11104#0) doesn't influence the FOCAS2 functions except
cnc_rdptaxitablestatus() and cnc_rdptsptablestatus().
cnc_rdptaxitablestatus
In case that parameter PCA(No.11104#0) is 1, the following information
becomes the value of workpiece coordinate.
In case that parameter PCA(No.11104#0) is 0, the following information
becomes the value of machine coordinate. The unit of position is the unit of
workpiece coordinate.
pos_value_e : The value of position command at executing block.
cnc_rdptsptablestatus
In case that parameter PCA(No.11104#0) is 1, the following information
becomes the value of workpiece coordinate.
In case that parameter PCA(No.11104#0) is 0, the following information
becomes the value of machine coordinate. The unit of position is the unit of
workpiece coordinate.
pos_value_e : The value of position command at executing block.
(During contour control mode)
cnc_rdptexedistalm
New alarm number 30,31,32, 33,34 and 35 are added to dist_alm_no.
dist_alm_no [ out ]
Specify pointer of alarm No. 0 is returned if there is no alarm.
Except that the return is EW_OK, the value indicated in (*dist_alm_no) is
invalid.
Sheet
Title
Draw
No.
FANUC Series 30i/31i
Specifications of Path Table Operation
Workpiece coordinate command
FANUC LTD
8/17
Ed. Date Design Description
Date Jun.06.’5 Desig. T.Watanabe Apprv. Y.Takeuchi
