Series 30i-MODEL A, Memory Card Program Operation/Editing Additional Manual Page 13

Additional Manual
Edit
Apprv.Desig.
Date
Design
Date
F
A
NUC Series 30i-MODEL A
Memory Card Program
Operation/Editing
A
-79368E
Sep.11.’03
11/12
page
Title
Draw
No.
Descri
p
tion
1.2.2 Program Editing Screen
When a memory card program is selected as a main program, the following editing operations
can be performed:
- Insertion
- Deletion
- Replacement
- Search
Limitation
When a program storage memory card is selected, the following operation cannot be
performed:
- Punching/reading program data to and from the memory card
Previous page
Next page

Contents Summary of Series 30i-MODEL A, Memory Card Program Operation/Editing Additional Manual

  • Page 1TECHNICAL REPORT NO. TMN 04/020E Date :Mar .30, 2004 General Manager of Software Laboratory FANUC Series 30i-A Newly additional functions 1. Communicate this report to: Your information only GE Fanuc-N, GE Fanuc-E FANUC Robotics MILACRON Machine tool builder Sales agency End user 2. Summary for Sale
  • Page 2FANUC Series30i –A newly additional functions Drawing number Functions 1 A-79227E External Data Input 2 A-79226E One Touch Macro call 3 A-79196E Temporary absolute coordinate setting 4 A-79354E System alarm 5 A-79349E Touch Panel Control 6 A-79253E Distance coded linear scale interface 7 A-79364E Li
  • Page 3FANUC Series 30i-MODEL A Memory Card Program Operation/Editing Specifications FANUC Series 30i-MODEL A Title Memory Card Program Operation/Editing Draw A-79368E No. Edit Date Design Description page 1/12 Date Sep.11.’03 Desig. Apprv.
  • Page 41.1 MEMORY CARD PROGRAM OPERATION/EDITING Overview A program held in a program storage file (named "FANUCPRG.BIN") on the memory card can be selected as a main program to perform memory operation. Moreover, the contents of a program storage file can be referenced using the program directory screen,
  • Page 5NOTE To use the functions for calling macros, using custom macros, and using a multiple repetitive canned cycle for turning, the options corresponding to the respective functions are required. ・Selection as a main program As a main program to be automatically executed in the memory mode, a memory ca
  • Page 64 System folder among the initial folders Search target folders are set in parameter No. 3457. NOTE For a memory card program, subprogram call using M code/S code/T code/particular addresses/the second auxiliary function or macro call using G code/M code can be specified. However, a program on the C
  • Page 71.1.3 Limitations and Cautions on Memory Card Programs Limitation When a program storage memory card is selected, the memory card cannot be used for the ordinary purposes listed below. To use a memory card in such a case, perform a "removal" operation to cancel the recognition of the program storage
  • Page 81.1.4 Creating a Memory Card Program Create a program storage file ("FANUCPRG.BIN") on a commercially available personal computer by using a memory card program creation tool. The number of program storage file entries (total number of program files and folders) can be selected from the following: ・
  • Page 9Example ・Contents of the program storage file ("FANUCPRG.BIN") Folder Program file not handled as program number Program file handled as program number Limitation ・The folder attribute/program file attribute cannot be set. FANUC Series 30i-MODEL A Title Memory Card Program Operation/Editing Draw A-7
  • Page 101.2 OPERATION SCREENS Overview The contents of a program storage file on the memory card can be displayed on the program directory screen. For information about a program storage file, see Subsection 1.1.4, "Creating a Memory Card Program". 1.2.1 Program Directory Screen When a program storage memor
  • Page 11Operation When displaying the contents of a program storage file or selecting a main program, select a program storage memory card by device change operation. ・Device change operation Insert a program storage memory card into the card slot then press the [DEVICE CHANGE] soft key. Next, select the pr
  • Page 12・Main program selection Pressing the [MAIN PROGRAM] soft key selects, as a main program, the program currently selected with the cursor. ・Display switching Pressing the [DETAIL] soft key switches folder/file display to detail display. Pressing the [OUTLINE] soft key switches the screen display to ou
  • Page 131.2.2 Program Editing Screen When a memory card program is selected as a main program, the following editing operations can be performed: - Insertion - Deletion - Replacement - Search Limitation When a program storage memory card is selected, the following operation cannot be performed: - Punching/r
  • Page 141.3 PARAMETER #7 #6 #5 #4 #3 #2 #1 #0 0138 MNC [Input type] Parameter input [Data type] Bit axis #7 MNC The external device subprogram call (M198) from a memory card is 0: Disabled 1: Enabled #7 #6 #5 #4 #3 #2 #1 #0 3457 SYS MC1 MC2 LIB [Input type] Parameter input [Data type] Bit axis #0 LIB The co
