1.3 PARAMETER
#7 #6 #5 #4 #3 #2 #1 #0
0138 MNC
[Input type] Parameter input
[Data type] Bit axis
# 7 MNC The external device subprogram call (M198) from a memory card is
0: Disabled
1: Enabled
#7 #6 #5 #4 #3 #2 #1 #0
3457 SYS MC1 MC2 LIB
[Input type] Parameter input
[Data type] Bit axis
# 0 LIB The common program directory "//CNC_MEM/USR/LIB/" of the
initial directories is
0: Set as a search directory.
1: Not set as a search directory.
# 1 MC2 MTB dedicated directory 2 "//CNC_MEM/MC2/" of the initial
directories is
0: Set as a search directory.
1: Not set as a search directory.
# 2 MC1 MTB dedicated directory 1 "//CNC_MEM/MC1/" of the initial
directories is
0: Set as a search directory.
1: Not set as a search directory.
# 3 SYS The system directory "//CNC_MEM/SYS/" of the initial
directories is
0: Set as a search directory.
1: Not set as a search directory.
