FANUC Series 30i-MODEL A
Tool management extension function
3. When G10 is set again
(Before re-registration)
G10L77P3; Set tool management data screen display
customization
N1 R1; Set No. as number 1
N2 R2; Set TYPE-NO. as number 2
N3 R3; Set MG as number 3
N4 R4; Set POT as number 4
N5 R-1; End
G11; Cancel the setting mode
(Re-registration)
G10L77P3; Set tool management data screen display
customization
N1 R5; Set T-INFORMATION as number 1
N3 R6; Set L-COUNT as number 3
N4 R7; Set MAX-LIFE as number 4
N5 R-1; End
G11; Cancel the setting mode
With G10 before re-registration, "No., Type Number, MG, and POT" are displayed. After
re-registration, "Tool Information, Blank Column, Life Counter, and Maximum Life" are
displayed.
NOTE
・ This setting is enabled when bit 0 (TDC) of parameter No. 13201 is set to 1.
・ Up to 20 pages can be set.
・ Be sure to specify an end.
・ If an item that requires the corresponding option is specified without
specifying the option, the item is displayed as a blank field.
・ No items after an end are displayed.
(Example) In the case of N1 → R1 (No.), N2 → R2 (Type Number), N 3 → R3
(MG), N4 → R-1 (End), N5 → R4 (Pot), only the items "No., Type Number,
and MG" are displayed on the screen.
・ If G10 L77 P3 is specified, the setting immediately before is initialized.
・ If an invalid value is set in R (tool management data display item), a blank
field is displayed.
Previous page
Next page

Contents Summary of Series 30i-MODEL A, Tool management extension function Additional Manual
