Series 30i-MODEL A, Tool management extension function Additional Manual Page 16

Additional Manual
A-79345E
Title
Draw
No.
Ed. Date Design Description
Date Jan.06.’04 Design. Apprv.
14/27
page
FANUC Series 30i-MODEL A
Tool management extension function
Standby position
First Second Third Fourth
1st path 121 122 123 124
2nd path 221 222 223 224
3rd path 321 322 323 324
4th path 421 422 423 424
5th path 521 522 523 524
6th path 621 622 623 624
7th path 721 722 723 724
8th path 821 822 823 824
9th path 921 922 923 924
10th path 1021 1022 1023 1024
・ Character number (P_)
Specify a character number. Up to three characters are displayed. If a character string to
be specified is shorter than three characters, specify 0 in the leading blank character
position(s). A character string immediately before 0 is displayed.
・ Character code (R_)
Set the name of a spindle position/standby position by using a character code.
・ For a character code, use ASCII code or Shift JIS code.
・ No character code data check is made.
