Series 30i-MODEL A, Tool management extension function Additional Manual Page 28

Additional Manual
A-79345E
Title
Draw
No.
Ed. Date Design Description
Date
Jan.06.’04 Design. Apprv.
26/27
page
FANUC Series 30i-MODEL A
Tool management extension function
1.1 ALARM
Alarm message
Number Message Description
5312 ILLEGAL COMMAND IN
G10 L75/76/77
In commands from G10 L75/L76/L77 to
G11, there is a format error, or a value
beyond the specifiable range is
specified. Correct the program.
Warning message
Warning message Description
INPUT IS REJECTED When the tool information TIM (#1) is set to 0, the tool
information REV (#5) is set.
WRITE PROTECT With the tool management data protection signal, key
input is disabled.
