Series 16i/160i-LB Descriptions Page 10

Descriptions
2.SPECIFICATIONS B-63662EN/01
- 4 -
CNCs which can be combined with a oscillator are Series16i-LB and
Series160i-LB.
: Standard specifications
: Standard optional specifications
: Not applicable
* : Specifications included in other specifications
Axis control
Item Specifications
16i-LB 160i-LB
Maximum total controlled axes
(machine controlled axes + loader controlled axes)
12 axes (macine 8 axes + loader 4 axes)
Controlled paths 1 path
Controlled axes 3 axes
Controlled axes expansion Max. 8 axes
Simultaneously controlled axes 3 axes
Simultaneously controlled axes expansion Max. 6 axes
Machine
controlled
axes
Axis control by PMC Max. simultaneous 4 axes
Controlled paths 1 path
Controlled axes Max. 4 axes
Simultaneously controlled axes Max. 4 axes
Loader
controlled
axes
Axis control by PMC Max. 4 axes
Axis name
3 basic axes: X, Y, Z;
Additional axes: U, V, W, A, B, or C
Simple synchronous control 4 pairs
Twin table control
Tandem control
Torque control PMC axis control required * *
Controlled axes detach
Least input increment 0.001mm, 0.001deg, 0.0001inch
Flexible feed gear Optional DMR
Dual position feedback
Fine acceleration/deceleration
HRV control
High-speed HRV control
Inch/metric conversion
Interlock
All axes/each axis/each axial direction/start
block/cutting block start
Machine lock All axes/each axis
Emergency stop
Overtravel
Stored stroke check 1
Stored stroke limit external setting
Stored stroke check 2
Stored stroke check 3
Stroke limit check before travel
Mirror image Each axis
Follow-up
Servo-off/mechanical handle
Backlash compensation
