Series 16i/160i-LB Descriptions Page 94

Descriptions
A.LASER SETTING SCREEN APPENDIX B-63662EN/01
- 88 -
(2) Laser setting
The laser setting screen consists of three pages shown below.
LASER SETTING O0000 N00000
CONTOURING POWER = 1000 W
FREQUENCY= 2000 Hz
DUTY = 100 %
PIERCING POW4R = 800 W
FREQUENCY= 1000 Hz
DUTY = 50 %
POWER SELECT = 0 (0:ALL,1:HLF)
POWER CONTROL = 0 (0:OFF,1:ON)
MIN. DUTY = 10 %
ASSIST GAS SELECT = 0
GAS FLOW SELECT = 1
>_ S 0 T0000
MDI **** *** *** 21:12:20
[ SET ][ TRACE ][ ][ ][ ]
LASER SETTING O0000 N00000
GAS FLOW 1 PRE-TIME = 1.00 S
PRE-PRES. = 100
WORK-PRES. = 200
AFTER-TIME = 1.00 S
AFTER-PRES. = 100
GAS FLOW 2 PRE-TIME = 1.00 S
PRE-PRES. = 100
WORK-PRE = 200
AFTER-TIME = 1.00 S
AFTER-PRE = 100
>_ S 0 T0000
MDI **** *** *** 21:12:20
[ SET ][ TRACE ][ ][ ][ ]
LASER SETTING O0000 N00000
GAS FLOW 3 PRE-TIME = 1.00 S
PRE-PRES. = 100
WORK-PRES. = 200
AFTER-TIME = 1.00 S
AFTER-PRES. = 100
>_ S 0 T0000
MDI **** *** *** 21:12:20
[ SET ][ TRACE ][ ][ ][ ]
