Series 16i/160i-LB Descriptions Page 12

Descriptions
2.SPECIFICATIONS B-63662EN/01
- 6 -
Item Specifications
16i-LB 160i-LB
Helical interpolation B
(Circular interpolation) + (Linear
interpolation for up to 4 axes)
Hypothetical axis interpolation
Skip G31
Reference position return G28
Reference position return check G27
2nd reference position return
3rd/4th reference position return
Floating reference position return
Normal-direction control
High-speed linear interpolation
Feed function
Item Specifications
16i-LB 160i-LB
Rapid traverse rate Max. 240 m/min (1µm)
Rapid traverse override F0, 25, 50, 100%
Feed per minute
Tangential speed constant control
Cutting feedrate clamp
Automatic acceleration/deceleration
Rapid traverse : linear
Cutting feed : exponential
Rapid traverse bell-shaped acceleration/deceleration
Positioning by optimum acceleration
Linear acceleration/deceleration after cutting feed
interpolation
Bell-shaped acceleration/deceleration after cutting feed
interpolation
Linear acceleration/deceleration before cutting feed
interpolation
Feedrate override 0% to 254%
2nd feedrate override 0% to 254%
Feed by F with one digit
Jog override 0% to 655.34%
Override cancel
External deceleration
Feed stop
Advanced preview control
AI contour control
Bell–shaped acceleration/deceleration before look–
ahead interpolation
High-precision contour control A 64-bit RISC engine is used.
Program input
Item Specifications
16i-LB 160i-LB
Tape code EIA RS244/ISO840 automatic recognition
Label skip
Parity check Horizontal parity, vertical parity
Control in/out
1 block
Optional block skip
9 blocks
Maximum value +/- with 8 digits
