Series 16i/160i-LB Descriptions Page 16

Descriptions
2.SPECIFICATIONS B-63662EN/01
- 10 -
Item Specifications
16i-LB 160i-LB
Power mate CNC manager
Communication function
Item Specifications
16i-LB 160i-LB
Embedded Ethernet
Ethernet Optional board is necessary.
PROFIBUS–DP Master/slave
DeviceNet Master/slave
FOCAS1/HSSB PORT2 function G32
Laser control function
Item Specifications
16i-LB 160i-LB
Output power command
Pulse frequency command 5 to 2000 Hz
Pulse duty command 0% to 100%
Piercing command G24
High-speed piercing command Including the piercing command
Assist gas command G32
Power override 0% to 200%
Duty override 0% to 150%
Frequency override 0% to 200%
Assist gas pressure override 0% to 200%
Power control
Laser screen display
Pulse enhanced function
Oscillator control using an M code
External alteration of piercing time
Return light monitoring function
Beam output delay function
Laser status output signal
Purge completed, gas pressure under
control, base discharging, discharge start
ready, etc.
Tracing control G13, G14
Tracing interlock function **
Cutting condition setting function
Edge machining function
Start-up function **
Step control
Optical path length compensation
Machinning restart function
High-speed machining function
Three-dimensional machining tool function
Item Specifications
16i-LB 160i-LB
Attitude control A
Attitude control B
Interaction control
Hand coordinate system travel
W-axis tracing control
Circular interpolation of space G12
Three-dimensional coordinate conversion G68, G69
Proximity point search
Spatial corner R insertion G33, G34
