Fanuc Laser C Series Improved Mirror Stage Additional Manual Page 4
Additional Manual
FANUC LASER C series
Improved Mirror Stage
03
MURAKAMI
030303
6-1-2. C4000-E
When the Cavity mirrors is specified with
A98L-0001-0756 (OC), A98L-0001-0757/B (RM).
ITEM Name Old spec. Q'ty New spec. Q'ty
STAGE A290-4540-V161
A290
-4540-V151
1 A290-4540-V163#C1
A290-4540-V153#C1
1
FITTING (attached) - A97L-0200-0648#L-2A-B 1
FITTING (attached) - A97L-0200-0651#N-06A-B 2
STAGE
(for Output Coupler)
MIRROR BASE A290-4530-X163 1 (unnecessary) -
STAGE A290-4540-V151
A290
-4540-V161
1 A290-4540-V153#C1
A290-4540-V163#C1
1
FITTING (attached) - A97L-0200-0648#L-2A-B 1
FITTING (attached) - A97L-0200-0651#N-06A-B 2
STAGE
(for Rear Mirror)
MIRROR BASE A290-4530-X163 1 (unnecessary) -
Note. Please make sure to confirm the specification of Output coupler and Rear mirror.
6-2. C2000-E
ITEM Name Old spec. Q'ty New spec. Q'ty
STAGE A290-4530-V201 1 A290-4523-V161#ST 1
FITTING (attached) - A97L-0200-0648#L-2A-B 1
FITTING (attached) - A97L-0200-0651#N-06A-B 2
STAGE
(for Output Coupler)
MIRROR BASE A290-4522-X160 1 (unnecessary) -
STAGE A290-4522-V151 1 A290-4523-V151#ST 1
FITTING (attached) - A97L-0200-0648#L-2A-B 1
FITTING (attached) - A97L-0200-0651#N-06A-B 2
STAGE
(for Rear Mirror)
MIRROR BASE A290-4522-X160 1 (unnecessary) -
6-3. C1000-E
ITEM Name Old spec. Q'ty New spec. Q'ty
STAGE A290-4514-V163 1 A290-4514-V165#ST 1
FITTING (attached) - A97L-0200-0651#L-06A-B 2
STAGE
(for Output Coupler)
MIRROR BASE A290-4515-X161 1 (unnecessary) -
STAGE A290-4514-V153 1 A290-4523-V155#ST 1
FITTING (attached) - A97L-0200-0651#L-06A-B 2
STAGE
(for Rear Mirror)
MIRROR BASE A290-4515-X160 1 (unnecessary) -
3/4
FANUC LTD
A-81053E-037
Description Design Date Edit.
01 021007 MURAKAMI
title
Sheet
Draw. No.
MURAKAMI Add C1000-E, C2000-E
Changed table 6-1-2
02 030127
Contents Summary of Fanuc Laser C Series Improved Mirror Stage Additional Manual
