AC SPINDLE MOTOR Alpha series Descriptions Page 213

Descriptions
APPENDIX
B–65152E/03
J. CONDITIONS OF IEC34
STANDARD CONFORMATIONS
213
This chapter describes about the conditions which are required for a, aP
a(HV) and aC series motors to be certified to conform IEC34 standard.
(1) When the motors meet the next restrictions and fill the following
conditions, they are certified as conforming to IEC–34–1.
Restrictions:Specifying #T0xx or #U0xx on the end of the
specifications, or manufacturing on and after April 1995.
Following letters (u, v, w, y and z) are limited as follows.
u: 1–8, v: 0, 3, 8 or 9, w: 0, 1, 6 or 7, y: 4 or 5, z: 2 or 3,
x: no limits
a series
Model name Motor spec. no.
a0.5 A06B–0866–Buvw, A06B–0866–Buvw#x0xx
a1 A06B–0850–Buvw, A06B–0850–Buvw#x0xx
a1.5 A06B–0851–Buvw, A06B–0851–Buvw#x0xx
a2
A06B–0852–Buvw, A06B–0852–Buvw#x0xx
a3
A06B–0853–Buvw, A06B–0853–Buvw#x0xx
a6 A06B–0854–Buvw, A06B–0854–Buvw#x0xx
a8 A06B–0855–Buvw, A06B–0855–Buvw#x0xx
a12 A06B–0856–Buvw, A06B–0856–Buvw#x0xx
a15 A06B–0857–Buvw, A06B–0857–Buvw#x0xx
a18 A06B–0858–Buvw, A06B–0858–Buvw#x0xx
a22
A06B–0859–Buvw, A06B–0859–Buvw#x0xx
a30
A06B–0860–Buvw, A06B–0860–Buvw#x0xx
a40
A06B–0868–Buvw, A06B–0868–Buvw#x0xx
a series (High speed models)
Model name Motor spec. no.
a1/15000 A06B–0850–Buvy, A06B–0850–Buvy#x0xx
a2/15000 A06B–0852–Buvy, A06B–0852–Buvy#x0xx
a3/12000 A06B–0853–Buvy, A06B–0853–Buvy#x0xx
a6/12000
A06B–0854–Buvz, A06B–0854–Buvz#x0xx
a8/8000
A06B–0855–Buvz, A06B–0855–Buvz#x0xx
a12/8000 A06B–0856–Buvz, A06B–0856–Buvz#x0xx
a15/8000 A06B–0857–Buvz, A06B–0857–Buvz#x0xx
a18/8000 A06B–0858–Buvz, A06B–0858–Buvz#x0xx
a22/8000 A06B–0859–Buvz, A06B–0859–Buvz#x0xx
a30/6000 A06B–0860–Buvz, A06B–0860–Buvz#x0xx
a P series
Model name Motor spec. no.
aP8 A06B–0825–Buvw, A06B–0825–Buvw#x0xx
aP12 A06B–0826–Buvw, A06B–0826–Buvw#x0xx
aP15 A06B–0827–Buvw, A06B–0827–Buvw#x0xx
aP18
A06B–0828–Buvw, A06B–0828–Buvw#x0xx
aP22
A06B–0829–Buvw, A06B–0829–Buvw#x0xx
aP30 A06B–0830–Buvw, A06B–0830–Buvw#x0xx
aP40 A06B–0831–Buvw, A06B–0831–Buvw#x0xx
aP50 A06B–0832–Buvw, A06B–0832–Buvw#x0xx
aP60 A06B–0833–Buvw, A06B–0833–Buvw#x0xx
J.1
SCOPE
