AC SPINDLE MOTOR Alpha series Descriptions Page 218

Descriptions
APPENDIX
J. CONDITIONS OF IEC34
STANDARD CONFORMATIONS
B–65152E/03
218
Thermal protection type specified by IEC34–11 is as follows.
T P 2 1 1
1: The category of the built–in thermal protection
1: Single level, by trip (no alarm)
2: Protection for slow and rapid overload variation
CAUTION
1 Crimp–style terminal
Use crimp–style terminals with a heat–shrink tube or an
insulating tube as those of the power line for the main motor
and for the fan motor in the terminal box. When connecting
the crimp–style terminal to the terminal block, ensure that
the clearance distance between each crimp–style terminal
is 1.5mm or more. (3 mm or more for a(HV) series)
2 For plastic terminal box
In case a metal conduit is connected to the plastic terminal
box, the conduit should be put to earth on the machine. (For
a30, a30/6000, a40, aP60, a30HV, a40HV, and a60HV,
those terminal boxes are made from aluminum alloy.)
J.6
THERMAL
PROTECTION
(IEC34–11)
J.7
OTHER
INFORMATIONS
