Series 21i/210i/210is - MA Operators manual Page 844

Operators manual

Page of 851

/ 851

Example

The compensation value set at Z-axis of the offset number 10 becomes

54.700 + (-2.583) = 52.117 mm under the following conditions:

• Specified H code: H10

• Value set at Z-axis of the offset number 10: 54.700 mm

• Amount of movement caused by manual feed along the Z-axis:

-2.583 mm

2.4 Changing the cutter radius compensation

This function can change the cutter radius compensation identified by the offset number

corresponding to a D code specified during automatic operation. If there is no valid tool

compensation (for example, when no D code has been issued since cycle start), no cutter

compensation change takes place even when axis movement is made manually.

Linear axis movement can change the cutter radius compensation. Rotation axis

movement cannot change it. When the cutter radius compensation is being changed,

manual feed cannot cause movement along more than one axis at a time.

Example

The compensation at offset number 15 becomes

6.500 + 2.379 + (-0.572) = 8.307 mm under the following conditions:

• Specified D code: D15

• Value set at offset number 15: 6.500 mm

• Amount of movement caused by manual feed along the X-axis: 2.379 mm

• Amount of movement caused by manual feed along the Y-axis:-0.572 mm

2.5 Changing the workpiece origin offset

This function can change the workpiece origin offset of an individual axis of the

workpiece coordinate system corresponding to G54 to G59 or G54.1P1 to P48

specified during automatic operation. There is a currently valid workpiece

coordinate system. So, axis movement made by manual feed causes the

workpiece origin offset of that workpiece to be changed. In addition, movement

along any axis (regardless of axis types, such as linear axes or rotation axes) can

change the workpiece origin offset. Moreover, manual feed can be made along

more than one axis at a time, when the workpiece origin offset is being changed.

Edit

Apprv.

Desig.

Sheet

Title

Draw

No.

Date

Design

Descri

tion

Date

FANUC Series16i/18i/21i–MA/MB

Changing Active Offset Value

with Manual Move.

02 030205 Overall revision

001106 S. Isohata E. Genma

A-78535E
