Tool axis compensation in tool axis direction Additional Manual Page 15

Additional Manual
Title
No.
FANUC Series 16i-MA/MB
Tool axis compensation in tool axis direction
A-78437E
Page
14/24
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
Restriction
- Limitation of Functions
In the mode for this function, the following functions can be used, but the condition of
each function cannot be changed
-
Inch/metric conversion
The alarm is issued when the condition is changed by G20 or G21 command.
-
Mirror image
The condition of DI signal cannot be changed.
-
Tool life management function
The tool length compensation use the amount of the tool specified by tool life
management function. The command for the tool life management function have to
command before tool axis direction tool length compensation mode.
-
One-digit F code feed
The feedrate cannot be changed by using manual pulse generator.
- Commands that cannot be specified
In the mode for this function, the following commands cannot be used. The alarm is
issued when the following commands are orderd. :
- Custom macro B
-
Exponentioal interpolation -G02.3,G03.3
-
Dwell -G04
-
Function concerning high-speed machining -G05 (exclude G05P10000 and 05P0)
-
AI precision control -G05.1Q1,G5.1Q0
-
Hypothetical axis interpolation -G07
-
Cylindrical interpolation -G07.1
-
Advanced preview control -G08 ( Please use AI HPCC function)
-
Polar coordinate interpolation -G12.1,G13.1
-
Polar coordinate command -G15,G16
-
Reference position return check -G27
-
Reference position return -G28
-
2
nd
Reference position return -G30
-
3
rd
/4
th
Reference position return -G30
-
Skip -G31
-
Threading -G33
-
Automatic tool length measurement -G37
-
Normal direction control -G40.1,G41.1,G42.1
-
Cutter compensation B -G41,G42,G39
(Cutter compensation C is available)
-
3 dimensional cutter compensation -G41
-
Wheel wear compensaton -G41
-
Tool offset -G45,G46,G47,G48
-
Programmable mirror image -G50.1,G51.1
-
Local coordinate system -G52
