Tool axis compensation in tool axis direction Additional Manual Page 24

Additional Manual
Title
No.
FANUC Series 16i-MA/MB
Tool axis compensation in tool axis direction
A-78437E
Page
23/24
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
19666 Tool holder offset for tool length compensation in tool axis direction
[Input type] Parameter input
[Data type] 2 word
[Unit of data] mm, inch (machine unit)
increment system IS-A IS-B IS-C unit
Millimeter machine
0.01 0.001 0.0001 mm
Inch machine
0.001 0.0001 0.00001 inch
[Minimum unit of data] Depend on the increment system of the reference axis
[Valid data range] -99999999 - +99999999
Set an offset value (tool holder offset value) for the machine-specific portion from
the rotation center of the rotation axis to the tool mounting position when the tool
length compensation in tool axis direction function is used.
19667 Shift vector in tool length compensation in tool axis direction
[Input type] Parameter input
[Data type] 2 word axis
[Unit of data] mm, inch (machine unit)
increment system IS-A IS-B IS-C unit
Millimeter
machine
0.01 0.001 0.0001 mm
Inch machine
0.001 0.0001 0.00001 inch
[Minimum unit of data] Depend on the increment system of the applied axis.
[Valid data range] -99999999 to +99999999
In the function for tool length compensation in tool axis direction , set the control
point shift vector. This parameter is valid when bit 5 (SVC) of parameter No.
19665 is 1 and bit 4 (SPR) of parameter No. 19665 is 1.
