FANUC Series 16i-MA/MB
Tool axis compensation in tool axis direction
A-78437E
Page
17/24
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
Parameter
#7 #6 #5 #4 #3 #2 #1 #0
19650 RAP RAM
[Input type] Parameter input
[Data type] Bitaxis
# 0 RAM
Specifies whether to use the axis as the rotation axis for tool length
compensation in tool axis direction.
0: Not used as the rotation axis.
1: Used as the rotation axis.
Select two axes from among rotation axes and set them as the rotation axes for these
purposes.
# 1 RAP
Specifies whether the rotation axis used for tool length compensation in
tool axis direction is an ordinary rotation axis.
0: Ordinary rotation axis.
1: Parameter axis.
19655 Axis number of the linear axis to which a rotation axis belongs
[Input type] Parameter input
[Data type] word axis type
[Va lid da t a ran ge] 0 - Ma x a xes
When a rotation axis turns about a linear axis, the linear axis is referred to as an
axis to which the rotation axis belongs, and is set using this parameter. For a
rotation axis that belongs to no linear axis, or for a linear axis, 0 is set.
Example:
Axis configuration: X, Y, Z, C, A
Linear axis: X, Y, Z
Rotation axis: A (turning about the X-axis), C (turning about the Z-axis)
In the above case, set the following:
Axis number Axis name Setting
1X0
2Y0
3Z0
4C3
5A1
