I/O Module Type-2 for Connector Panel, Connection Manual Additional Manual Page 20
Additional Manual
EDIT.
SHEET
DRAW. NO.
CUST.
TITLE
20
/
29
DESCRIPTIONDESIG.DATE
I/O module type-2 fo
r
Connector board
Connection manual
A-80950E
FANUC LTD
13. Manual Pulse Generator Connection
Connection is the same as connector panel I/O module(A03B-0815-C002)
JA3
(PCR-EV20MDT)
1 HA1 11
2 HB1 12 0V
3 HA2 13
4 HB2 14 0V
5 HA3 15
6 HB3 16 0V
7 17
8 18 +5V
9 +5V 19
10 20 +5V
Manual pulse generator #1
(M3 screw terminal)
3 4 5 6
+5V 0V HA1 HB1
Manual pulse generator #2
(M3 screw terminal)
3 4 5 6
+5V 0V HA2 HB2
Manual pulse generator #3
(M3 screw terminal)
3 4 5 6
+5V 0V HA3 HB3
Base module
HA1
HB1
+5V
0V
HA2
HB2
+5V
0V
HA3
HB3
+5V
0V
1
2
9
12
3
4
18
14
5
6
20
16
Sheld
7BK
7WH
5RD
5BK
8RD
8BK
4RD
3BK
9BK
9WH
6RD
1BK
HA1
HB1
+5V
0V
HA2
HB2
+5V
0V
HA3
HB3
+5V
0V
HA1 #1
HB1
+5V
0V
HA3 #3
HB3
+5V
0V
HA2 #2
HB2
+5V
0V
5
6
3
4
5
6
3
4
5
6
3
4
Ground
p
late
Cable Wire
Cable wiring
Recommended wire material：A66L-0001-0286(#20AWG×6 pair ＋ #24AWG×3 pair)
Recommended Connector：A02B-0120-K303(including the follow connector and case)
(Connector：FI40B-2015S(Hirose Electric Co., Ltd))
(Case： FI-20-CV5(Hirose Electric Co., Ltd))
Recommended Cable：A02B-0120-K841(7m)(for connecting three manual pulse generator)
A02B-0120-K848(7m) (for connecting two manual pulse generator)
A02B-0120-K847(7m) (for connecting one manual pulse generator)
(These cables do not include the wire shown in the above figure)
Terminal block Manual pulse generator
