FANUC Pulse Input Type Digital Servo Adapter, Connection Manual (Hardware) Additional Manual Page 39

Additional Manual
Dra
w
No.
Title
SheetDescri
p
tionDesi
g
n Date Edit
FANUC Pulse Input Type
Digital Servo Adapter
Connection Manual (Hardware)
A-77226EN
/
39
(5) When the cable is run outside the cabinet, use a common shield cable. For the
cable use a bundled sealed cable 34 pin cable with shield (soldering type)
OKI DENSEN CO,.LTD SFX-S 34-7/0.127 3030-SV(20266)K
FANUC Specification
A66L-0001-0308#S34S
Clamp the cable shield with the cable clamp on the grounding plate of the cabinet
on the built-in I/O side.
(6) For details of the signal specifications, see Section 6.2.
(7) Ensure that the cable is securely plugged into the unit. Otherwise, problems such
as signal transfer errors may occur.
(8) The DO points of this built-in I/O module are designed to be turned off when a
system alarm occurs in the PDSA and when the PDSDA power is switched off.
