2 INSTALLATION
2.1 ENVIRONMENTAL REQUIREMENTS
The peripheral units and the control unit have been designed on
the assumption that they are housed in closed cabinets. In this
manual "cabinet" refers to the following:
In operation 0`C to 55`C
Ambient Temperature
In store or
transportation
-20`C to 60`C
Relative humidity 30% to 95%(no condensation)
Vibration In operation 0.5G or less
In store or
transportation
1.0G or less
Meters above sea level In operation Up to 1000m
In store or
transportation
Up to 12000m
Environment
Inter of units: Each unit should be placed
in a cabinet to keep it from pollutants
(such as dust, coolant, organic solvents,
acid, corrosive gas, and salt).
Heat sink of outer of cabinet: The heat
sinks should be protected from direct
exposure to coolant, lubricant, and metal
chips.
Radiation
(ionizing or nonionizing)
If a unit is to be used in an environment
where it is likely to be exposed to
radiations (such as microwave, ultraviolet
rays, laser beams, and X-rays),
a shielding provision should be available
for it.
2.2 POWER SUPPLY CAPACITY
The following unit requires a power supply of 24 VDC±10%
(including instantaneous change and ripple).
Notes
1 The PDSA requires an additional 24V power supply for DOs.
2 Use memory cards that consume no more than 2W.
Power supply capacity for control unit
Unit Power supply capacity Heat loss
PDSA 1.5 A 25 W
Separate detector interface unit 0.9 A (Basic unit)
1.5 (Basic unit + additional unit)
9 W
14 W
