FANUC Series16i /18i – MB/TB
Retract for high-speed remote buffer
A
-78086EN/03
2000.03.15
02 2005.02.22 Out of frame 2 is added
03 2005.11.04 Out of frame 3 is corrected
(Note 1) The setting value is changed according to the interpolation time of the
data of the high-speed remote buffer.
In case of the interpolation time is 8msec :
The time constant becomes a multiple of eight.
In case of the interpolation time is 4msec :
The time constant becomes a multiple of four.
In case of the interpolation time is 2msec :
The time constant becomes a multiple of two.
In case of the interpolation time is 1msec or less:
The time constant is a setting value.
It becomes the value of each multiple rounded up, except for the multiple
of 8, 4, and 2.
Example) In case of setting value is 9
1) In case of 8msec : It becomes 16msec
2) In case of 4msec : It becomes 12msec
3) In case of 2msec : It becomes 10msec
4) In case of 1msec or less : It becomes 9msec
Number
7522 Retract value
[ Data type ] 2-word axis
[ Unit of data ]
Increment system IS-A IS-B IS-C Unit
Millimeter input 0.01 0.001 0.0001 mm
Inch input 0.001 0.0001 0.00001 inch
Rotation Axis 0.01 0.001 0.0001 deg
[ Valid data range ] -99999999 to 99999999
At the retract operation of the high-speed remote buffer, retract value of each axis
is set.
