Specifications of Servo-Spindle synchronous control function Supplement to Manual Page 9

Supplement to Manual
A-78808E
Sheet
Title
Draw
No.
Ed.
Ed.Ed.
Ed. Date
DateDate
Date Design
DesignDesign
Design Description
DescriptionDescription
Description
Date
DateDate
Date May.29.’02 Desig.
Desig.Desig.
Desig. A.Fukumoto Apprv
ApprvApprv
Apprv.
..
. T.Endo
FANUC Series 16i /18i -TB
Specifications of Servo-Spindle synchronous control
function
9/
17
3 Signal
3.1 Detail of signals
Servo-Spindle switch signal
SVSP (G022#7)
[Classification]
[Classification][Classification]
[Classification] Input signal (Switching ‘β’ in the figure)
[Function]
[Function][Function]
[Function] The servo motor becomes spindle control mode by turning on SVSP signal, and
the speed command is output to the servo motor in the rotating speed set in
12BIT of signal SVR1I-SVR12I beforehand. At this time, output signal SVSPM is
turned on.
The spindle control mode is released by turning off signal SVSP. At this time,
output signal SVSPM is turned off.
Note
As for the spindle control mode inside, the coordinates value is not updated.
Therefore, the relation between coordinates value and an actual machine position
is lost.
Spindle control mode signal
SVSPM (F090#7)
[Classification]
[Classification][Classification]
[Classification] Output signal
[Function]
[Function][Function]
[Function] This signal indicates that a spindle control mode inside.
[Output condition]
[Output condition][Output condition]
[Output condition] The signal is set to 1 in spindle control mode.
Rotating speed control signal
SVR01I – SVR12I (G021#0 ~ G022#3), SVGN(G022#5)
[Classification]
[Classification][Classification]
[Classification] Input signal
[Function]
[Function][Function]
[Function] •Speed input signal of servo motor (SVR01I∼SVR12I)
Please input the value obtained by the undermentioned formula by the
binary.
4096
speed Spindle Max.
SpeedTarget
einput valu Signal ×=
• Rotating direction signal (SVGN)
Specify the ratating direction of servo motor.
1: Minus direction
0: Plus direction
Spindle control mode acc/deceleration completion signal
SVAR (F090#6)
[Classification]
[Classification][Classification]
[Classification] Output signal
[Function]
[Function][Function]
[Function] This signal notifies the acceleration of the servo motor in the spindle control
mode has completed.
[Output condition]
[Output condition][Output condition]
[Output condition] When the de-and acceleration ends, this signal becomes '1' in spindle control
mode.
