2 Canned cycles for drilling (G83 - G89)
The canned cycles for drilling includes the one, which outputs
M03/M04/M05/M19 automatically. You must select the spindle to control in
the canned cycle by commanding spindle select P code before executing a
canned cycle. The spindle select P code must be commanded with the
spindle function M code or the S command.
(By the way, the P code command in the canned cycles for drilling becomes
dwell time specification.)
3 Multiple command of auxiliary function
When using multiple M commands in a single block (M3B(No.3404#7)=1),
please be careful of the following.
Please set equal to or less than 65535 values to parameters No.13550,
No.13554, No.13558, No.13559.
When doing a command like the following example, each M code is changed
into the M code for the spindle which is chosen with the P code. And then, a
changed value is output to each signal.
(Example)
- M03 M04 M05 P11;
- M19 M04 P12;
Please use code grouping function to avoid that a command like the
above is executed.
4 The function which decides the M code for the command by the
parameter There is a function which decides the M code for the command by
the parameter setting.
(Example)
- Spindle positioning (Parameter No.4960, No.4961, No.4962)
- Rigid tapping (Parameter No.5210, No.5212)
And so on
When using such a function, set a value except spindle function M code
(M03, M04, M05 and M19).
Restrictions
The function cannot be used with the Manual numerical command.
