SERIES 15i-16i-18i-21i MODEL A Operators manual Page 26

Operators manual
B-63454EN/01 3. CONNECTION
-17-
3.1 CONNECTION BETWEEN THE CNC AND TELEPHONE LINE
3.1.1 Connecting a Modem Card to the CNC
For the Series 16i/18i/21i
- After turning off the power to the CNC, insert the modem card
into the slot on the front of the CNC’s LCD unit.
- Turn on the power to the CNC. The modem card is automatically
initialized.
- Whether the modem card has been initialized normally can be
checked using the screen displayed by the following key
operations:
Press function key [OFFSET],
, and then soft key <MODEM>.
If the modem card is initialized normally, "OK" is displayed at the end
of the screen. If the modem card fails to initialize normally, the modem
card itself or a component such as a connector may be faulty.
WARNING
It is dangerous to insert a modem card when the
power to the CNC is on. An expected operation may
occur as a result.
NOTE
For an explanation of how to use the modem card,
see the operator’s manuals provided with the modem
card and mobile telephone. When a mobile
telephone line is used, normal communication may
be impeded by the signal reception status even if the
modem card and its connection are normal.
For the Series 15i
- After turning off the power to the CNC, insert the modem card
into the slot on the front of the CNC’s LCD unit.
- Turn on the power to the CNC, then set the CNC parameters to
initialize the modem card.
- Whether the modem card has been initialized normally can be
checked on the screen displayed by the following key operations:
Press function key [OFFSET SETTING], soft key <CHAPTER>, and
the soft key <MODEM SETTING>.
If the modem card is initialized normally, the modem type is displayed.
If the modem card is not initialized normally, the modem card itself or a
component such as a connector may be faulty.
For details of the modem setting screen, refer to the relevant section in
"FANUC Series 15i Operator’s Manual (Operation) (B-63324EN)".
