SERIES 15i-16i-18i-21i MODEL A Operators manual Page 35

Operators manual
3. CONNECTION B-63454EN/01
-26-
3.5.3 Line Connection/Disconnection (when Connecting an
External Modem Via the RS-232-C Interface)
For the Series 16i/18i/21i
A connection can be made/broken in the same way as when a modem
card is used.
(See also: Section 3.5.1)
(See also: Section 3.5.2)
Before making a connection, set bit 0 of CNC parameter No. 0002 to 1.
After line disconnection, set bit 0 of parameter No. 0002 to 0.
(See also: Section 3.3.2)
For the Series 15i
A connection can be made/broken in the same way as when a line is
connected using a modem card.
(See also: Section 3.5.1)
(See also: Section 3.5.2)
3.5.4 Line Connection/Disconnection (when Making a Direct
Connection Via the RS-232-C Interface)
For the Series 16i/18i/21i
Operation from the host software is not required. To make a
connection, set bit 0 of CNC parameter No. 0002 to 1. To break the
connection, set bit 0 of parameter No. 0002 to 0.
(See also: Section 3.3.2)
For the Series 15i
In communication setting, set RS-232-C for Device, then choose Phone
and the Dial. The line is connected.
